Description:
| Model | L6-226 4x4 Utility Wagon, Utility Delivery | L6-226 4x2 Station Wagon, Utility Delivery |
|---|---|---|
| Engine | L6-226 | L6-226 |
| Type | L-head | L-head |
| Number of cylinders | 6 | 6 |
| Bore | 3 5/16" | 3 5/16" |
| Stroke | 4 3/8" | 4 3/8" |
| Displacement | 226.2 cu. In. | 226.2 cu. In. |
| Ignition Timing | 5° BTC | 5° BTC |
| Compression Ratio | 6.86 to 1 | 6.86 to 1 |
| Compression Pressure | 125 to 140 psi. | 125 to 140 psi. |
| Horsepower (max. brake) | 105 at 3600 rpm. | 105 at 3600 rpm. |
| Horsepower (SAE) | 26.33 | 26.33 |
| Torque (max. at 1400 rpm) | 190 lb-ft. | 190 lb-ft. |
| Wheelbase | 104 1/2" | 104 1/2" |
| Tread: Front | 57" | 57" |
| Tread: Rear | 57" | 57" |
| Height (over all) | 72" | 71 1/2" |
| Length (over all) | 176 1/4" | 176 1/4" |
| Width (over all) | ||
| Utility Wagon | 71 3/4" | 71 3/4" |
| Utility Delivery | 68" | 68 1/8" |
| Ground Clearance | 8 1/2" | 7 3/8" |
| Gross Vehicle Weight (GVW) | 4500 lb. | 4300 lb. |
| Weights (approximate): Shipping (less fuel, oil, water) | ||
| Utility Wagon | 3206 lb. | 2971 lb. |
| Utility Delivery | 3008 lb. | 2859 lb. |
| Capacities: | ||
| Fuel Tank | 12 qt. | 12 qt. |
| Cooling System: | ||
| Without heater | 12 qt. | 12 qt. |
| With heater | 13 qt. | 13 qt. |
| Model | F4-134 4x4 Utility Wagon, Utility Delivery | F4-134 4x2 Station Wagon, Utility Deliver |
| Engine | F4-134 | F4-134 |
| Type | F-head | F-head |
| Number of Cylinders | 4 | 4 |
| Bore | 3 1/8" | 3 1/8" |
| Stroke | 4 3/8" | 4 3/8" |
| Displacement | 134.2 cu. In. | 134.2 cu. In. |
| Ignition Timing | 5° BTC | 5° BTC |
| Compression Ratio | 6.9 to 1 | 7.4 to 1 |
| Compression Pressure | 120 to 130 psi. | 120 to 130 psi. |
| Horsepower (max. brake) | 72 at 4000 rpm. | 75 at 4000 rpm. |
| Horsepower (SAE) | 15.63 | 15.63 |
| Torque (max. at 2000 rpm) | 114 lb-ft. | 114 lb-ft. |
| Wheelbase | 104 1/2" | 104 1/2" |
| Tread: Front | 57" | 57" |
| Tread: Rear | 57" | 57" |
| Height (over all) | 74" | 73 1/2" |
| Length (over all) | 176 1/4" | 176 1/4" |
| Width (over all) | ||
| Utility Wagon | 71 /34" | 71 /34" |
| Utility Delivery | 68 1/8" | 68 1/8" |
| Ground Clearance | 8 1/2" | 7 3/8" |
| Gross Vehicle Weight (GVW) | 4500 lb. | 4300 lb. |
| Utility Delivery | 4500 lb. | |
| Weights (approximate): Shipping (less fuel, oil, water) | ||
| Pickup or Utility Wagon | 3093 lb. | 2858 lb. |
| Stake or Utility Delivery | 2895 lb. | 2746 lb. |
| Curb (including fuel, oil, water): | ||
| Pickup or Utility Wagon | 3228 lb. | 2993 lb. |
| Stake or Utility Delivery | 3030 lb. | 2881 lb. |
| Capacities: | ||
| Fuel Tank | 15 gal. | 15 gal. |
| Cooling System: | ||
| Without heater | 11 qt. | 11 qt. |
| With heater | 12 qt. | 12 qt. |
* Excerpt from the Service Manual for Jeep Utility Vehicles page 4
